Specifications:

• Accuracy Class: C2
• Brand Name: PUSHTON
• Capacity: 100-200KG
• Certification: CE
• Certification: RoHS
• Creep In 30 Minutes: 0.02%F.S
• Environmental Protection: IP67
• Excitation Voltage: 10DC
• Hysteresis: 0.03%F.S
• Input Resistance: 400±10Ω
• Is Smart Device: NO
• Material: Aluminium Alloy
• Maximum Excitation Voltage: 15V AC/DC
• Model Number: PSD-X2
• Non-linearity: 0.03%F.S
• Origin: CN(Origin)
• Output: Analog Signal
• Output Resistance: 350±3Ω
• Power Supply: 5-15V
• Rated Load: 200kg
• Rated Output: 2.0±0.004mv/v
• Safe Overload: 150%F.S
• Temperature Effect Span: 0.015%F.S/10℃
• Type: F Type Load Cell/Force Sensor
• Type: LoadCell
• Ultimate Overload: 300%F.S
• Zero Balance: ±1%F.S
